CAMPBELL Foot Valves
#Grup produk P109416478
Spesifikasi
| Application - Valves | Pumps |
|---|---|
| Connection Type - Valves | FNPTxFNPT |
| Cracking Pressure - Valves | 0.5 |
| Design | Spring |
| Flow Design | Single |
| Full Flow - Valves | No |
| Item - Foot Valves | Foot Valve |
| Max. Steam Pressure - Valves | Not Rated |
| Minimum Valve Temperature (°F) | 35 |
| Mounting Orientation - Valves | Horizontal; Vertical |
| Seat Material - Valves | Bronze |
| Spring Material | Stainless Steel |
| Standards | ASTM B62 |
| Strainer Material | Stainless Steel |
| Valve Body Design | Inline |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Foot valves install at the end of pump lines to prevent water loss.
Feature
Item - Foot Valves Foot Valve Flow Design Single Design Spring Application - Valves Pumps Valve Body Design Inline Body Material - Valves Bronze Strainer Material Stainless Steel Pipe or Tube Size - Valves 1 1/2 in Connection Type - Valves FNPT x FNPT Max Steam Pressure - Valves Not Rated Max Water Pressure - Valves 250 psi Cracking Pressure - Valves 0.5 psi Min Temp - Valves 35 Degrees F Max Temp - Valves 180 Degrees F Mounting Orientation - Valves Horizontal VerticalUlasan Produk
