Parker Food & Beverage PTFE Tubing
#Grup produk P109416335
Spesifikasi
| UNSPSC | 31160000 |
|---|---|
| Application | Air; Beverages; Fluid; Food; Inert Gas |
| Autoclavable | Yes |
| Bend Radius (inch) | 1 |
| Burst Pressure | 520 |
| Clarity | Semi-Clear |
| Coil Weight (lbs) | 0.5 |
| Color | White |
| Elongation (%) | 200 to 450 |
| Features | Non-Leaching; Non-Wetting; Resistant to Extreme Heat or Cold -100°F to +500°F; Resists Ultra-Violet Rays; Self-Extinguishing Plastic |
| Fitting Compatibility | Compression |
| Flexibility | Flexible |
| Flow Application | Chemical Transfer; Fluid Handling; Semiconductor |
| For Environment | Chemical |
| For Fluid Type | Chemicals; Compressed Air/Inert Gas |
| For Location | Indoor; Outdoor |
| Hardness | Shore D 50 to 65 |
| Industry Application | Instrumentation; Medical/Pharmaceutical; Semiconductor |
| Inside Diameter (inch) | 3/16 |
| Material | PTFE |
| Maximum Operating Pressure | 130 |
| Maximum Operating Temperature (°F) | 500 |
| Maximum Vacuum Pressure (in Hg) | 28 |
| Minimum Operating Temperature (°F) | -100 |
| Outside Diameter (inch) | 1/4 |
| Outside Diameter Tolerance | +/-0.005 |
| Overall Length (ft) | 25 |
| Peristaltic Pump Compatible | No |
| Resistance Properties | Chemical Resistant; Corrosion Resistant; Heat Resistant; UV Resistant |
| Standards | 21 CFR 177.1550; UL 94 V-0; USP Class VI Compliant |
| Stripe Color | No Stripe |
| Tensile Strength | 7000 |
| Vacuum Rated | Vacuum Rated |
| Wall Thickness (inch) | 0.031 |
| Weight Per Foot (lbs/ft) | 0.02 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
This PTFE tubing has a broad temperature range for food and beverage processing. It's flexible, nonflammable, and heat-resistant. This food-grade tubing is safe for use in food and beverage lines, dispensing equipment, and potable water systems.
Feature
Tubing Application Air Beverages Fluid Food Inert Gas Color White Food Application Food and Beverage Hardness Shore D 50 to 65 Inside Diameter 3/16 in Material PTFE Material Trade Name Not Applicable Maximum Operating Pressure 130 psi Maximum Operating Temperature 500 Degrees F Maximum Vacuum Pressure 28 in Hg Outside Diameter 1/4 in Overall Length 25 ft Peristaltic Pump Compatible No Resistance Properties Chemical Resistant Corrosion Resistant Heat Resistant UV ResistantUlasan Produk
