DUCTMATE Duct Access Door
#Grup produk P109409292
Spesifikasi
| UNSPSC | 40141901 |
|---|---|
| Door Height (inch) | 8 |
| Door Shape | Rectangular |
| Door Thickness (inch) | 1 1/8 |
| Door Width (inch) | 12 |
| Duct Diameter (inch) | 17 to 18 |
| Finish | Galvanized |
| For Duct Diameter (inch) | 17; 18 |
| For Duct Shape | Round |
| For Media Type | Air |
| Latch Type | Thumbscrews |
| Material | Steel |
| Material Fabrication | Stamped |
| Material Thickness (ga) | 22 |
| Maximum Pressure Rating (in WC) | 20 |
| Maximum Temperature Rating (°F) | 2300 |
| Mounting Stud Length (inch) | 2 |
| Mounting Style | Sandwhich |
| Number of Mounting Stud | 2 |
| Rough Opening Height x Width (inch) | 7 5/8x11 3/4 |
| Standards | ASTM D746; UL 94 HB; UL 94 HF 1 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
High-temperature curved access doors allow access to the internals of a round duct used for high-temperature ventilation applications such as combustion exhaust. The high-temperature sealing gasket keeps the airstream inside when the door is secured.
Feature
Duct Access Door Door Height 8 in Door Shape Rectangular Door Thickness 1 1/8 in Door Width 12 in Fire Rating Not Rated For Nominal Duct Diameter 17 in 18 in Hinge Style None Insulation Material Not Applicable Latch Type Thumbscrews Material Thickness 22 ga Maximum Temperature Rating 2 300 Degrees F Mounting Stud Length 2 in Number of Mounting Stud 2 Observation Port Height Not Applicable Observation Port Material Steel Observation Port Width Not ApplicableUlasan Produk
