VC903 Features:
*Auto/manual ranges
*True RMS measurement
*550V protection in resistance and capacitance ranges
*LCD display, MAX display 6000 counts
*Sample rate: 3 times per second
*Backlight
*Data hold
*Polarity identification Low voltage indication
*1000A high current measurement, low current measurement Auto power off
*Main measurements: AC/DC Voltage, AC/DC Current, Resistance, Capacitance, Diode and Continuity Testing,Temperature, Frequency and duty cycle.
Packing List:
1*Digital clamp meter
1*A pair Test leads
1*Temperature Probe
1*English manual
1*Pouch bag
ZOTEK Auto Range Clamp Meter
#Grup produk P108487646
Spesifikasi
| Dimensions (mm) | 240x90x45 |
|---|---|
| Frequency | 99.99Hz/999.9Hz/9.999KHz/99.99KHz/999.9KHz/9.999MHz (±0.1+2); |
| Temperature | (-20~1000)°/(-4~1832)° ±(2.5%+5) |
| Capacitance | 10nF(±5.0+20),100nF/1000nF/10uF/100uF/1000uF(±2.0%+5),10mF(±5.0%+5) |
| DC Volt | 600mV(±1.0%+10), 6V/60V/600V/1000V(±0.5%+3) |
| AC Volt | 600mV(±3.0%+3),6V/60V/600V/750V(±1.0%+3) |
| Duty cycle | 1% to 99%(±0.1%+2) |
| Measurement Mode | Double-integral style A/D transform |
| Over Range Indication | OL |
| Relative Humidity | < 80% |
| Resistance | 600Ω/6K/60K/600K/6M(±0.5%+3),60MΩ(±1.5%+3) |
| Supply Power | 3V (1.5V AA batteries*2 pcs not included) |
| Working Environment | 0~40° |
