Autonics Pressure Sensors PSM Series
#Grup produk P108469464
Kondisi Barang:
Authorized Partner
Sebelum PPN:
Rp2.299.900 - Rp3.699.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Control Output Repeat Error | ±0.1% F.S. ±min. display interval |
|---|---|
| Current Consumption (mA) | Max. 100 (add 20 for RS485 communication) |
| Display Method | 7-segment LCD method; PV display part: Red or Green; SV display stion :Green; Channel display part: Red |
| Display Pressure Range | Depending on pressure type, pressure unit (refer to ' Rated Pressure and Max. Display Pressure Range') |
| Input Connection | Sensor connector terminal (for CNE-P04, sold separately) |
| Display Digit | PV display part, SV display part: 4-digit, channel display part: 1-digit |
| Output Connection | 20-pin hirose connector terminal (HIF3BA-20D-2.54R, 20-wire flat cable, sold separately) |
| Power Consumption (W) | Max. 3 |
| Power Supply (V) | 12-24 DC ±10% (ripple P-P: Max. 10%) |
| Power for External Sensor (V/mA) | 12-24 DC/40, for each channel (Max. current 1-4CH: Max. 100mA, Max. current 5-8CH: Max. 100mA) |
| Protection Circuit Control Output | Short circuit protection circuit, reverse polarity protection circuit |
| Temperature Display Control Output (°C) | 0-50: ±0.2% F.S. ±2-digits (based on 25), -10 to 0: ±0.3% F.S. ±2-digit |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
The PSM series multi-channel pressure indicators can display up to 4 or 8 channels of measured values from analog pressure sensors. When used with PSS series pressure sensors, the units can automatically identify the sensor models, pressure type and range without requiring additional configuration. Users can also easily copy parameters between channels, and the Auto Shift function allows stable output by adjusting the determined pressure level to match the change in pressure in reference to the original pressure.
