Sample depths down to 7.9 meters (26 feet).
Features a single-turn potentiometer for speed control, ON indicator, and three-position power/reversing switch
Reversible flow and prime/purge function
Includes a Masterflex L/S Easy-Load pump head
Also accepts Masterflex L/S Standard pump heads (order separately)
Floats up to 30 minutes if dropped in water when case is closed and latched
IP54-rated control panel protects against inclement weather and splashing water
Rechargeable battery - ideal for field applications
The Masterflex L/S portable sampler is designed for the ultimate in portability and versatility. Run up to four hours on the self-contained 12 VDC rechargeable battery, or indefinitely from any AC or 12 VDC power supply. Charge the internal battery from an AC power supply or a DC voltage source of lower voltaic potential than the battery itself. The variable-speed drive has a top speed of 400 rpm, allowing you to adjust the flow rate to the needs of your application.
Pump is encased in a high-visibility yellow housing for easy recognition and recovery in the field.
Delivery information: Includes masterflex L/S Easy-Load pump head (07514-12) and AC adapter with 3.7-m (12-ft) cable.
Master Flex Portable Sampler
#Grup produk P108381005
Spesifikasi
| Maximum Flow Rate (ml/minute) | 1100 |
|---|---|
| Width (cm) | 31 |
| Height (cm) | 24 |
| Washdown Capable | No |
| Drive IP Rating | IP 54 |
| Accuracy (%) | ±5 |
| Control Type | Analog Variable Speed |
| Drive | Portable Sampling Drive |
| Duty cycle | Continuous |
| Housing Material | HDPE, anodized aluminium, stainless steel, and polyester |
| Length (cm) | 38 |
| Maximum Speed (rpm) | 400 |
| Minimum Speed (rpm) | 70 |
| No. of Channels | 1 |
| No. of Rollers | 4 |
| Open-Head Sensor | No |
| Power Voltage (V) | 90-260AC; 12DC; 50/60 Hz; 2.2 A @ 115; 1.1 A @ 230 |
| Pump Head | 07514-12 (L/S Easy-Load Head) |
| Pump Series | L/S |
| Tubing Sizes Accepted | L/S 15, 24 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Warning
Image on this page only as Representative Image, Please check the specifications of each size and color for detailsFeature
Features a single-turn potentiometer for speed control, ON indicator, and three-position power/reversing switchReversible flow and prime/purge function
Includes a Masterflex L/S Easy-Load pump head
Also accepts Masterflex L/S Standard pump heads (order separately)
Floats up to 30 minutes if dropped in water when case is closed and latched
IP54-rated control panel protects against inclement weather and splashing water
Rechargeable battery - ideal for field applications
