GW INSTEK Spectrum Analyzer
#Grup produk P108250273
Spesifikasi
| Size (mm) | 296x115x152 |
|---|---|
| Amplitude Accuracy (dB) | ±2 (1GHz, Span 5MHz) |
| Amplitude Reference Level Setting Range (dBm) | +20 to -40 |
| Displayed Average Noise Level (dBm) | ≦ -100 |
| Frequency Accuracy (kHz) | ±50 |
| Frequency Characteristics (kHz-GHz) | 150 - 3 |
| Package Size (mm) | 255x385x200 |
| Power Measurement Items | ACPR, OCBW, CHANNEL POWER |
| Power Supply (V AC) | 100 to 240 (at 50/60Hz) |
| RBW Accuracy | ± 25% |
| RBW Range | 30kHz, 100kHz, 300kHz, 1MHz |
| Resolution (MHz) | 0.1 |
| Span Settings | 1MHz - 3GHz, Full span, Zero span |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Warning
Image on this page only as Representative Image, Please check the specifications of each model number for details.Feature
Provided with marker measurement function (markerx5, peak markerx5)Display three traces in different colors (green, orange, yellow)
