Mitutoyo Analog Screw Thread Micrometer Inch With Interchangeable Anvil
#Grup produk P108033232
Spesifikasi
| Range (inch) | 0-1 |
|---|---|
| Graduation (inch) | 0.001 |
| Technology | Mechanical |
| Ratchet/Thimble | Ratchet Stop |
| Optional Accessories | 126-800, 126-810 |
| SPC Output | No |
| Spindle feed error (inch) | 0.00015 |
| Units | Inch |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
The Mitutoyo screw thread micrometer uses optional V-Anvil and conical spindle inserts interchangeably to precisely measure pitch diameters of metric or unified screw threads. A ratchet-stop mechanism provides uniform pressure on a workpiece for precise, repeatable measurements.
Feature
'- Available in Metric and Inch models- Optional interchangeable 60 degree and 55 degree V-Anvil and conical spindle inserts are precision ground hardened, high-grade steel
- Ratchet mechanism provides an audible click to ensure measurement is performed at a constant force
- Satin chrome finish on the sleeve and laser etched measurements on thimble for easier reading
- Frame has a baked enamel finish for durability and longer lifespan
- Includes a standard bar except for 0-25mm and 0-1” models
- Supplied in fitted plastic case
