ASPURE Ambient Monitor
#Grup produk P107997526
Spesifikasi
| Target Particle Size (µm) | 0.5 or higher |
|---|---|
| Sampling Time (minute) | 5 |
| Measurement Update Time (s) | 5 |
| Humidity Measurement Range (%RH) | 10 to 95 |
| Air Cleanliness Class Display | The LED air cleanliness class (Class Equivalent Values) level displays, Class 100 100.000 equivalent to Class 10 equivalent to 100-1.000-2.000-3.000-5.000-10.000-20.000-30.000-50.000-100.000 |
| Accessories | Mounting metal bracket for wall |
| Air Cleanliness Class Measurement Method | Light scattering system |
| Alarm Output | LED display open collector output in air cleanliness class (Class Equivalent Values) |
| Mounting posture | Vertical (Within three degrees of ±) |
| Power Supply (V AC) | 100 (at 50/60Hz) |
| Sampling System | Uses an updraft by internal heater |
| Size (mm) | 148.9x100x36 |
| Temperature Measurement Range (°C) | 0 to 60 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Warning
Image on this page only as Representative Image, Please check the specifications of each model number for detailsFeature
＜SEM-1100・SEM-1150＞ Display results equivalent to class100～100000 at 10 levelsDisplay cleanliness updating every 5seconds
Measuring both temperature and humidity, and versatile environmental measuring is available
＜SEM-1100EXA＞ External output of the particle level, temperature and humidity is available
Issue alarm sound when receiving the alarm output signal sent from the body（alarm ON/OFF switching system）
Possible to output measuring results to external equipment by the alarm output connector
Possible to input measuring results to PC by data logger such as electric current logger（1-2366-02）
＜SEM-ST＞ This is desktop stand to install ambient monitor and output unit
