7000APL Microprocessor Panel Meter, 1/8 DIN, Selectable by Jenco
Panel mount digital thermometer user selectable for type via external dip switch with front panel touch switch for selecting °C or °F. Features bright red LED display and a 1/8 DIN plastic housing. Model 7001APL has Min/Max switch for display of Min/Max temperatures. Available for types. J, K, T, E, N, R, S, DIN-T and DIN J. Ambient range-10 to 60°C. 115/230V AC operation.
CMOS microcomputer design
Cold junction compensation
T/c calibration for types-k,j,t,e,n,r,din t,din j
T/c type, resolution and unit default select by dip switch
Wide temperature ranges
Error indicators
Front panel °C/°F selectable
1°C/0.1°C resolution selectable
Min/max display
0.56 led display
Easy to install, metal mounting bracket
Wide operation temperature
High accuracy and low cost
JENCO Microprocessor Thermocouple
#Grup produk P107778781
Sebelum PPN:
Rp7.099.900 - Rp7.499.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Display | 0.56 High LED Display |
|---|---|
| Cold Junction Temperature Compensation (°C) | 0.03 (0.03°F) |
| Annuciators | C,f |
| Common Mode Noise Rejection (db min) | 120 |
| Compatible for | J, K, T, E, N, R, S Type & Temperature C Or F |
| Dimensions (mm) | 99x48x104 (99 Behind Mounting Panel) |
| Lead Resistance Effect | Less Than 5 uv for 1k ohms of Lead Resistance |
| Normal Mode Rejection Ratio (db) | Over 80 (at 50/60 hz) |
| Power Consumption (V/A) | 3.5 |
| Rated Accuracy (°C) | 18 to 28 |
| Temperature Coefficient (Outside of 10 to 28°C) (ppm/°C) | 40 (Typical) |
