695-ORP 2-Wire DC LCD ORP Transmitter, NEMA-4 Case by Jenco
2-wire 4-20 mA ORP transmitter in a sealed NEMA-4 enclosure with an LCD display powered by 11 to 80 Volts DC. Span is selectable any 100 to 1400 mV unit by dipswitch. Connections are BNC for ORP.
Input/output isolated
Nema 4x enclosure
Large LCD display
4 to 20 mA output
High accuracy
BNC input connector
High input impedance
4 to 20 mA output scalable to any 100mv unit span
Wide range power supply ,12 to 80 VDC
JENCO 2-Wire ORP Transmitter
#Grup produk P107777825
Spesifikasi
| Power Source (V DC) | 11 to 80 |
|---|---|
| Dimensions | 4.92x2.95x3.94 (NEMA 4x Case) |
| Span (mA) | Any 100 to 1400 (Unit), Selectable with Internal d |
| Connector | BNC |
| Input Impedance | Greater Than 10exp(12) ohms |
| Range (mV) | ORP: -700 to 700 |
| Accuracy | ORP: 1 mV ± 1 Digit |
| Operating Temperature (°C) | -10 to 60 |
| Output (mA) | 4 to 20 |
| Resolution (mV) | ORP: 1 |
