Hanna Instruments Panel-mounted ORP Digital Controller with Matching Pin
#Grup produk P107661560
Spesifikasi
| mV Range (mV) | ±2000 |
|---|---|
| mV Resolution (mV) | 1 |
| mV Accuracy (mV) | ±2 |
| mV (ORP) Calibration | Automatic, single point, at 0 and 350 or 1900 mV |
| Temperature Range (°C) | -9.9 to 120 |
| Temperature Resolution (°C) | 0.1 |
| Alarm Relay | 1 contact output SPDT, 5A-250 VAC, 5A-30 VDC (resistive load), fuse protected (2A, 250V fast fuse) |
| Analog Ouput Signal | Galvanically isolated: 0-1 mA, 0-20 mA and 4-20 mA, 0-5 VDC, 1-5 VDC and 0-10 VDC |
| Digital Output Signal | RS232 bi-directional optoisolated |
| Dimensions (mm) | 144x144x170 |
| Environment Temperature (°C) | 0 to 50 (32 to 122°F); RH max 95% non-condensing |
| Max. Oscillation Frequency (MHz) | 4 |
| Over Current Protection (mA) | 400 ; 250V fast fuse |
| Panel Cut Out (mm) | 140x140 |
| Power Consumption (V/A) | 15 |
| Power Supply (V) | 230 AC ±10%; 50/60Hz |
| Set Point | 1 or 2 contact outputs SPDT 5A-250 VAC, 5A-30 VDC (resistive load), fuse protected (2A, 250V fast fuse) |
| Temperature Accuracy (°C) | ±0.5 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
The mV600 controllers have been engineered with a number of outstanding features to meet all of your process control needs. mV600 offer a multitude of possibilities from ON/OFF or proportional dosage to analog recorder output and alarm. A host of self-testing features and user-friendly functions make mV600 a great value.
