ORP Transmitter with 4-20 mA Galvanically Isolated output; with LCD display, HI 8615(L): ±1000 mV / 4-20 mA, HI 8615(L)-01: ±1999 mV / 4-20 mA.
HI-8615LN ORP Transmitter
This improved transmitter features two controls (one for 4 mA and one for 20 mA) to compensate for electronic drift and ambient temperature.
The HI-8615LN uses a universal BNC socket for quick and secure connection of any ORP electrode with a BNC connector.
An IP65 rating and a rugged ABS casing provide optimum protection even in harsh environments making this instrument ideal for chromium hexavalent reductions and water sanitation. The transmitter can be connected to HANNA meters HI-8512, HI-8720 or any recorders, PCs or data monitors that accept 4 to 20 mA input.
The HI-8615LN has a Liquid Crystal Display (LCD).
BNC Connection - BNC is one of the most commonly used connector types in pH meters and electrodes. Compatible with any meter or electrode that uses BNC connectors.
Replaceable Electrode - No need to replace the whole meter when the electrode needs replacing. Spare and replacement electrodes are available for this product.
Hanna Instruments ORP - Transmitter
#Grup produk P107657983
Sebelum PPN:
Rp13.999.900 - Rp20.999.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Dimensions (mm) | 165x110x71 (6.5x4.3x2.8inches) |
|---|---|
| Recorder Output (mA) | 4-20 (isolated) |
| Calibration | offset: +-100mV; +-0.8mA; slope 90 to 110%; +-0.8mA |
| Resolution (mV) | 1 ; 0.01 mA |
| Power Supply (V) | 20-36DC |
| Accuracy (mV) | '±5; ±0.02mA at 20°C/68°F |
| IP Protection | IP65 |
| Input Impedance (ohm) | 10¹² |
| Load Resistance (ohm) | Max 500 |
| Range (mV) | ±1999; 4-20mA |
