Mitutoyo Quick Image
#Grup produk P107647384
Spesifikasi
| View Field (mm) | 32x24 |
|---|---|
| Measuring Range (X, Y axex) (mm) | 200x100 |
| Travel Range (Z axis) (mm) | 100 |
| Accuracy (Measurement Accuracy Withinthe Screen) | High Resolution Mode: ±2µm/Normal mode: ±4µm |
| Accuracy (Repeatability Within the Screen (±2o) | High Resolution Mode: ±1µm/Normal Mode: ±2µm |
| Accuracy (Measurement Accuracy (U1xy) | ± (3.5+0.02L) µm, L: Arbitray Measuring Length (mm) |
| Effective Stage Glass Size (mm) | 242x140 |
| Guaranteed Temperature Accuracy (°C) | 20±1 |
| Illumination | Transmitted Light: Green LED Telecentric Illumination, Co-Axial Light: White LED, Ring Light: Quadrant White LED |
| Imaging Device | 3 Megapixel, ½, Color-Compatible |
| Main Unit Mass (kg) | Approx. 74 |
| Maximum Stage Loading (kg) | Approx. 10 |
| Measurement Mode | High Resolution Mode/Normal Mode |
| Monitor Magnification | 7.6X |
| Optical System (Depth of Focus) (mm) | High Resolution Mode: ±0.6 /Normal Mode: ±11 |
| Optical System (Working Distance) (mm) | 90 |
| Optical System Magnification (Telecentric Optical System) | 0.2X |
| Power Supply (V AC) | 100-240 (50/60Hz) |
