-Wide range of detectors.
-In addition to the standard universal hydraulic impactor (type D), users can choose from a wide range of special hydraulic impactors for special measuring tasks.
-Type D+15: narrow design for measuring in grooves.
-Specimen requirements: Min. specimen thickness of 5mm or more and mass of 5kg or more (However, a specimen of mass of 0.1 to 5kg is measurable by securing to a massive base) Testing point: 5mm or more from edge of specimen, 3mm or more between testing points Specimen surface roughness: Ra of 2µm or less
-Functions: Auto angle compensation, Offset, OK/NG judgement, Hardness scale conversion, Data storage (1800 data entries), Statistical analysis (Average value, Max. value, Min. value, Dispersion), Auto sleep function, Impact counter display function
Mitutoyo Leeb Impact Device
#Grup produk P107646206
Spesifikasi
| Data Output | RS-232C, SPC |
|---|---|
| Power Supply | Battery LR6 (2 pcs.) or AC Adapter (Optional) |
| Impact Device | Impact Hammer With Integrated Carbide-Ball Tip, D Scale (ASTM A 956) |
| Display unit | 7-Segment LCD |
| Hardness Display Range (HL) | Leeb Hardness: 1 to 999 |
| Connector Cable For | HH-411 |
| DP-1VA (264-505) | 965013 |
| IT-016U 264-016-10 Hardmatic Table | 937387 |
| Pin | Round 6 |
| U-WAVE-T | 02AZD790E |
| USB-ITN | 06AFM380E |
