This is a highly accurate, precision form measuring system developed to give you the highest
accuracy as well as high flexibility and analytical capability.
-The Roundtest RA-H5200 offers the following benefits:
-Its integrated vibration isolator helps you to measure within the best conditions.
-It has a high measuring range and loading mass.
-The user friendly software, ROUNDPAK, gives you easy drag and drop usage and a wide range of parameters.
-ROUNDPAK also has easy-to-use part programming and single measurement functions.
-A.A.T. (Automatic Adjustment Table) gives you fully automatic centering and leveling.
-There is an auto follow function for easy and quick pre-centering of the workpiece.
-Rotational accuracy:
Radial:
(0,02+0,00035H) µm
H: Measuring height from turntable surface (mm)
Axial:
(0,02+0,00035X) µm
X: Radial distance from center (mm)
-Software: ROUNDPAK, FORMTRACEPAK-AP (optional for roughness detection unit)
-Optional accessories: Other optional and standard accessories are listed later in this section for accessories and styli.
Mitutoyo Centering Chuck
#Grup produk P107644828
Spesifikasi
| Vertical Travel (mm) | 550 |
|---|---|
| Centering/Leveling Adjustment 1 | AAT |
| Max. Probing (mm) | Ø400 |
| Max. Probing Diameter (mm) | 400 |
| Max. Workpiece (mm) | ø680 - 680 |
| Centering Range (mm) | ±5 |
| Leveling Range (°) | ±1 |
| Max. Probing Depth (mm) | 85 (Minimum ID : ø32 mm) 50 (Minimum ID : ø7 mm) |
| Max. Probing Height (mm) | AS : 350, AH: 550 (Above Turntable Surface) |
| Max. Turn Table Loading (kg) | 65 |
| Parallelism with Rotation Center (µm/mm) | AS : 0.2/350, AH : 0.32/550 |
| Perpendicularity to Rotation Center (µm/mm) | 0.5/200 |
| Rotation Speed (rpm) | (2, 4, 6, 10), (Auto Centering: 20) |
| Straightness (µm/mm) | AS/AH : 0.05/100, AS : 0.14/350, AH : 0.2/550 |
