Ball nose milling cutter, conical design with neck, z=4
MBN105
Application: Suitable for machining workpiece materials up to 55 HRC.
Radial Contour Tolerance: ±0.005 if d1 ≤ 6 mm; ±0.01 if d1 > 6 mm
MAPAL OptiMill-Uni-Rough
#Grup produk P107124209
Spesifikasi
| D1 (mm) | 3 |
|---|---|
| R (mm) | 0.3 |
| φ (°) | 1.5 |
| d2 h5 (mm) | 6 |
| Cutting Material | HP803 |
| Diameter of Milling Cutter (mm) | 3.00-12.00 |
| Dimension L1 (inch) | 75 |
| Dimension L3 (mm) | 40 |
| Dimensions l2 (mm) | 3.5 |
| Dimensions l5 (mm) | 6 |
| Helix Angle (Degree) | 30 |
| Number of Cutting Edges | 4 |
| Spesifications | MCR105-030-0030-4000C075-HP803 |
| Type | C |
| Working Depth at x° Incline 0.5° | 10.57 |
| Working Depth at x° Incline 1.5° | 40.96 |
| Working Depth at x° Incline 1° | 20.84 |
| Working Depth at x° Incline 3° | 43.01 |
| d3 (mm) | 4.72 |
| d5 (mm) | 2.94 |
