Corner radius milling cutter, cylindrical design with neck, z=4
MCR104
MAPAL OptiMill-Uni-HPC-Finish
#Grup produk P107124120
Spesifikasi
| D1 (mm) | 3 |
|---|---|
| R (mm) | 0.5 |
| d2 h5 (mm) | 6 |
| Dimensions l2 (mm) | 4.5 |
| Application | Suitable for machining workpiece materials up to 55 HRC. |
| Cutting Material | HP803 |
| Diameter of Milling Cutter (mm) | 3.00-12.00 |
| Dimension L1 (inch) | 60 |
| Dimension L3 (mm) | 10 |
| Helix Angle (Degree) | 30 |
| Number of Cutting Edges | 4 |
| Radial Contour Tolerance | ±0.005 if d1 ≤ 6 mm; ±0.01 if d1 > 6 mm |
| Spesifications | MCR104-030-0050-1000X060-HP803 |
| Type | A |
| Working Depth at x° Incline 0.5° | 11.21 |
| Working Depth at x° Incline 1.5° | 11.96 |
| Working Depth at x° Incline 1° | 11.63 |
| Working Depth at x° Incline 3° | 13.3 |
| d3 (mm) | 2.94 |
