Ball nose milling cutter, conical design with neck, z=4
MBN105
Application: Suitable for machining workpiece materials up to 55 HRC.
Radial Contour Tolerance: ±0.005 if d1 ≤ 6 mm; ±0.01 if d1 > 6 mm
MAPAL OptiMill®-Uni-HPC-Silent
#Grup produk P107124087
Spesifikasi
| D1 (mm) | 6 |
|---|---|
| R (mm) | 3 |
| φ (°) | 1 |
| d2 h5 (mm) | 10 |
| Cutting Material | HP801 |
| Diameter of Milling Cutter (mm) | 3.00-12.00 |
| Dimension L1 (inch) | 100 |
| Dimension L3 (mm) | 50 |
| Dimensions l2 (mm) | 6.9 |
| Dimensions l5 (mm) | 12 |
| Helix Angle (Degree) | 30 |
| Number of Cutting Edges | 4 |
| Spesifications | MBN105-060-0300-5000B100-HP801 |
| Type | A |
| Working Depth at x° Incline 0.5° | 26.74 |
| Working Depth at x° Incline 1.5° | 53.32 |
| Working Depth at x° Incline 1° | 51.67 |
| Working Depth at x° Incline 3° | 56.62 |
| d3 (mm) | 7.23 |
| d5 (mm) | 5.9 |
