FLUKE Electrical Tester and AC Voltage Detector Kit
#Grup produk P106956629
Spesifikasi
| Shock and Vibration | Sinusoidal vibration per MIL-PRF-28800F for a Class 2 instrument |
|---|---|
| AC Bandwidth (Hz) | 45 to 66 |
| Duty Cycle (s) | For voltages between 240 V and 600 V the duty cycle is 30 s on / 300 s off; For voltages above 240 V the tester must connect to a voltage source only for a MAXIMUM of 30 s and then disconnect for a MINIMUM of 300 s |
| Voltage Hazard LED | LEDs turn on at voltages > 30 V AC/DC ± 35% |
| LEDs | LEDs turn on between 90% and 100% of the indicated voltage on the LED, except for the 12 V LED which turns on between 50% and 100% |
| LCD Resolution | 0.1 V for voltages < 50 V, 1 V for voltages ≥ 50 V; 0.01 kΩ for resistance measurement |
| Battery Life (hour) | 40 |
| Battery Type | 2 x AAA |
| GFCI Test Current | 100 V - 150 V @ 6 mA - 9 mA AC, 150 V - 240 V < 12 mA |
| Humidity (without condensation) (%) | 0 to 95 (0°C to 30°C); 0 to 75 (30°C to 40°C); 0 to 45 (40°C to 50°C) |
| Maximum Voltage (V) | 1000 AC/DC (working); 600 AC/DC (measureable) |
| Measurement category | ISA-82.02.01 (IEC 61010-1 Mod) Second Edition, CAN/CSA-C22.2 No. 61010-1 Second Edition, IEC 61010 - 1 to 1000 V CAT III/600 V CAT IV, Compliance to NFPA 70E |
| Operating Altitude (m) | 2000 |
| Operating Temperature (°C) | -10 to 55 |
| Size (mm) | 33x54x193 |
| Standard Input Test Current (mA) | <5 |
| Storage Temperature (°C) | -30 to 60 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Buy a Combo Kit and SAVE!The T+PRO-1AC Kit combines two troubleshooting tools, in one convenient combo pack. The T+PRO Electrical Tester has all of the advantages of a traditional solenoid tester, with added functionality, but none of the typical drawbacks. With voltage measurement, continuity, built-in flashlight, GFCI trip capability, and the legendary ruggedness and reliability of Fluke, the tester is an excellent choice for most residential, commercial, and industrial applications. The 1AC-II is the pocket-sized voltage detector that can quickly test for energized circuits-a "must have for any electrician.
