Temperature input terminal with smart function.
Almost the same functions as the analog input terminal such as scaling function and comparator function can be used.
Features such as "time count within set temperature range" and "temperature difference detection between input channels" specific to the temperature input terminal are also available.
OMRON DRT2-TS04 Temperature Input Terminal
#Grup produk P106932717
Sebelum PPN:
Rp9.699.900 - Rp9.799.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Storage Temperature (°C) | -25 to 65 |
|---|---|
| Vibration Resistance | 10 to 150Hz, double amplitude 0.7mm |
| Current Consumption (mA) | 70 or less (at DC24V), 110 or less (at DC11V) |
| Noise Resistance (V) | Compliant with IEC61000-4-4: 2.0 |
| Number of Input/Output Points | 4 inputs and 4 channels on the master (occupy 8 channels when 1/100 display mode is selected) |
| Communication Power Supply Voltage (V) | DC 11-25 (supplied from communication connector) |
| Conversion Cycle (ms) | 250/4 points |
| Insulation Resistance (MΩ) | 20 or more (initial value) (DC100V mega) |
| Mounting Strength (N) | 50, 10 (rail direction) |
| Operating Ambient Temperature (°C) | -10 to 55 (with no icing or condensation) |
| Screw Tightening Torque (N m) | M3: 0.5 |
| Shock Resistance (m/s²) | 150 |
| Terminal Strength (N) | Pull 50 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Ulasan Produk
Tidak ada ulasan
