OMRON Socket With Loose Wire Crimp Lock (Set Type) XG5
#Grup produk P106930250
Spesifikasi
| Material (Lever) | (Lock lever) POM resin (UL94 HB)/Black |
|---|---|
| Insertion/Removal Durability (times) | 50 |
| Total Insertion Force | Number of contacts inserted x 1.96 N or less |
| Contact Resistance (miliΩ) | 20 or less (20mV or less, 100mA or less) |
| Insulation Resistance (MΩ) | 1000 or more (at 500 VDC) |
| Material (Housing) | Glass-filled PBT resin (UL94 V-2)/Black |
| Operating Ambient Temperature (°C) | -55 to 105 (no freezing at low temperatures) |
| Rated Voltage (V) | AC 250 |
| Shape | Socket with lock (set type) |
| Single Removal Force (N) | 0.29 or more |
| Standard | RoHS directive, ML standard (MIL-C-83503), UL standard (file No.E103202) |
| Withstand Voltage (V/minute) | AC 500 (leakage current 1mA or less) |
