Smart slaves with a three-stage terminal block that are easy to understand and have no wiring.
Easy wiring. No joint tightening. The wiring location is also easy to understand.
No need for a relay terminal block terminal.
Adopts a cassette detachable structure of the circuit section.
OMRON Remote I/O Terminal (3-Stage Terminal Block Transistor Type) DRT2-D16TA (-1)
#Grup produk P106921881
Spesifikasi
| Rated Voltage | (Internal circuit power supply) Supply from communication connector (I / O power supply) DC24V |
|---|---|
| Type of Terminal | (I / O) M3 screw terminal |
| Atmosphere | No corrosive gas |
| Insulation Resistance (MΩ) | 20 or more (between isolated circuits) |
| Shock Resistance (m/s2) | 150 (3 times for 6 directions in 3 axes) |
| Ambient Relative Humidity (RH) | 25 to 85 (non-condensing) |
| Noise resistance | Compliant with IEC61000-4-4, 2kV (power line) |
| Operating Ambient Temperature (°C) | -10 to +55 |
| Storage Temperature (°C) | -20 to +65 |
| Type of Terminal Fitting | DIN 35mm rail mounting, M4 screw mounting |
