Body length 20mm, round body Φ12 series.
High brightness and uniform surface illumination.
Drilling is easy due to the round body.
Small and good operation feel.
OMRON Pushbutton Switch (Rectangular) (Non-Illuminated) (Round Body ɸ12) A3C
#Grup produk P106918902
Spesifikasi
| Protection Class | IP40 |
|---|---|
| Storage Temperature (°C) | -25 to 65 (with no icing or condensation) |
| Shock Resistance Destruction (m/s²) | Up to 500 |
| Electrical Durability (times) | 100K or more |
| Insulation Resistance (MΩ) | 100 or more (with DC500V mega) |
| Minimum Applicable Load (V-mA) | DC 5-1 |
| Mounting Hole Diameter P (mm) | 12 |
| Operating Ambient Temperature (°C) | -10 to 55 (with no icing or condensation) |
| Operating Force OF (N) | Up to 2.45 |
| Overall Movement TT (Reference) (mm) | About 3.5 |
| Pollution Degree (Environment to Use) | 3 (IEC60947-5-1) |
| Pretravel (PT) (mm) | Up to 2.5 |
| Return Force (N) | Min 0.29 |
| Terminal Shape | Solder terminal |
