1.27mm pitch connector contact pitch 1.27mm 2-row arrangement that responds to high-density mounting and miniaturization of high-level electronic devices. High-density mounting is possible.
The connection with the board is a 4-row staggered arrangement (1.27mm x 1.905mm).
Adopting a leaf contact structure realizes strong and smooth insertion and removal.
Achieves a mating length of 3.1mm, greatly improving the margin.
Maintains a stable contact force through the press-fit part
Furthermore, the use of gold / palladium plated contacts further improves contact reliability.
Standardized with all-pole locking pins to prevent falling down during soldering.
Screwing onto the board is also possible.
UL standard certified product (file No.E103202).
Cannot be mated with XH3 / XH4 half pitch connectors. 1.27mm pitch connector contact pitch 1.27mm to meet high density mounting and miniaturization 2 rows arrangement enables high density mounting.
The connection with the board is a 4-row staggered arrangement (1.27mm x 1.905mm).
Adopting a leaf contact structure realizes strong and smooth insertion and removal.
Achieves a mating length of 3.1mm, greatly improving the margin.
Maintains a stable contact force through the press-fit part Furthermore, the use of gold / palladium plated contacts further improves contact reliability.
Standardized with all-pole locking pins to prevent falling down during soldering.
Screwing onto the board is also possible.
UL standard certified product (file No.E103202).
Cannot be mated with XH3 / XH4 half pitch connectors.
OMRON Half-Pitch Connector (For Board-To-Board Connection) XH2
#Grup produk P106900851
Spesifikasi
| Type | Plug |
|---|---|
| Rated Current (A) | 0.5 |
| Rated Voltage (V) | AC125 |
| Insulation Resistance (MΩ) | 103 or more (at 500 VDC) |
| Contact Resistance (miliΩ) | 30 or less (20 mV or less, 100 mA or less) Combination of XH2A-@@42 and XH2B-@@41 |
| Insertion / Removal Durability (Times) | 400 |
| Operating Ambient Temperature (°C) | -55 to +105 (no freezing at low temperatures) |
| Standard | RoHS directive, UL standard (File No.E103202) |
| Total Insertion Force (N) | Number of poles x 0.78 or less |
| Total Removal Force (N) | Number of poles x 0.10 or more |
| Withstand Voltage (V/minute) | AC650, 1 (leakage current 1mA or less) |
