Easy expansion! Expansion I / O unit.
One expansion unit can be combined with one digital I / O slave.
As a result, various I / O combinations such as 16 inputs + 8 outputs are possible, expanding the possibilities of system construction.
The number of points can be expanded flexibly depending on the combination.
I / O detachment structure shortens startup time and improves maintainability.
A variety of maintenance-related data necessary for improving productivity, such as equipment aging and equipment operation information, can be collected.
OMRON Expansion Unit XWT-ID08 (-1)/OD08 (-1)/ID16 (-1)/OD16 (-1)
#Grup produk P106898237
Spesifikasi
| Current Consumption (mA) | (Communication power supply) 5 or less (at DC24V), 5 or less (at DC11V) |
|---|---|
| Storage Humidity (%) | 25 to 85 (no condensation) |
| Atmosphere | No corrosive gas |
| Ambient Relative Humidity (RH) | 25 to 85% (non-condensing) |
| Insulation Resistance (MΩ) | 20 or more (between isolated circuits) |
| Noise resistance | Compliant with IEC61000-4-4, 2kV (power line) |
| Number of Circuits | 8 points / common |
| Operating Ambient Temperature (°C) | -10 to +55 |
| Power Supply Voltage (V) | (Communication) 14 to 26.4 DC (I/O) 20.4 to 26.4 DC (24 V DC -15 to +10%) |
| Shock Resistance (m/s2) | 150 (3 times for 6 directions in 3 axes) |
| Storage Temperature (°C) | -25 to +65 |
| Vibration Resistance | 10-60Hz 0.7mm double amplitude, 60-150Hz 50m/s2 80min in each of X, Y, Z directions |
| Withstand Voltage (V) | AC500 (between isolated circuits) |
