Wiring can be reduced with a connector.
Switch mounting is a one-touch snap-fit type.
Bi-directional operation type with free mounting direction.
OMRON Connector Type Detection Switch D2X
#Grup produk P106893597
Spesifikasi
| Protection Class | IEC IP00 |
|---|---|
| Resistive Load (A) | 0.1 |
| Operating Temperature Range (°C) | -10 to 70 60% RH or less (with no icing or condensation) |
| Allowable Operation Frequency (times/minute) | (Mechanical) 60, (Electrical) 30 |
| Shock Resistance Destruction (m/s²) | 500 or more |
| Allowable Operating Speed (mm/s) | 0.1-100 |
| Contact Resistance (miliΩ) | 200 or less (initial value) |
| Durability (times) | (Mechanical) 1million or more (60/min), (Electrical) 50K or more (30/min) |
| Insulation Resistance (MΩ) | 100 or more (with DC250V insulation resistance meter) |
| Operating Humidity Range (%RH) | 45 to 85 (at 5 to 35°C) |
| Rated Voltage (V) | DC 30 |
| Shock Resistance Malfunction (m/s²) | 300 or more |
| Vibration Resistance (Malfunction) | 10 to55Hz double amplitude 1.5mm |
| Withstand Voltage | (Between homopolar terminals) 250 VAC 50/60 Hz for 1 min, (between charged metal part and ground) 250 VAC 50/60 Hz for 1 min |
