OMRON Amplifier Separation Proximity Sensor High-Precision Digital Type Sensor Head E2C-EDA
#Grup produk P106889992
Spesifikasi
| Protection Class | IEC standard IP67 |
|---|---|
| Type | Amplifier separate type |
| Head Shape | Circle |
| Sensor Shape | Cylindrical |
| Detection Distance (mm) | 0.6 |
| Detection Target | Magnetic metals (Non-magnetic metals reduce the detection distance.) |
| Accessories | Preamplifier mounting bracket, instruction manual |
| Ambient Humidity (%RH) | During use and storage: 35 to 85 (with no condensation) |
| Ambient Temperature (°C) | During use/storage: -10 to 60 (Sensor head only, excluding preamplifier. No icing or condensation.) |
| Case Material | Brass |
| Connection Method | Connector |
| Cord Length (m) | 2.5 (between head and preamp/2) |
| Dimensions (mm) | Φ3×18 |
| Family Type | E2C-E |
| Hysteresis | Variable |
| Impact Durability (m/s²) | 500 X, Y, Z directions 3 times each |
| Insulation Resistance (MΩ) | Between charging part batch and case: 50 or more (at DC500V megger) |
| Material (Detection Surface) | Heat-resistant ABS |
| Product Code | E2C 3009D |
| Repeatability (µm) | 1 |
| Shield Shape | Shield |
| Standard Sensing Object (mm) | Iron (S50C) 5x5x3 |
| Vibration Resistance (Durability) | 10 to 55 Hz, 1.5 mm double amplitude, 2 hours each in X, Y, and Z directions |
| Withstand Voltage (V) | Between charging part batch and case: AC1000 50/60Hz 1min |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Ulasan Produk
Tidak ada ulasan
Buka WhatsApp
