JAE Cable Clamp
#Grup produk P106582196
Spesifikasi
| Applicable Connector | N / MS3101B, N / MS3106B, N / MS3108B and junction shell (CA2120) |
|---|---|
| Shell Size | 20, 22 |
| Bushing Part Number | N/MS3420-12 |
| Connector Shape | cable clamp |
| Dimensions d (mm) | 65.7 (reference) |
| Dimension E (mm) | 19 |
| Insulation Resistance (MΩ) | 5000 |
| Dimension A (mm) | 37.3(±0.8) |
| Dimension W (mm) | 1-3/16-18UNEF-2B |
| Dimension C (mm) | 23.8(±0.8) |
| Dimension B (mm) | phi 34.9(±0.8) |
| Dimension F (mm) | phi 15.9 |
| Dimension G (mm) | phi 18.8 |
| Finish Material | (Ground nut, clamp saddle) Aluminium Alloy / galvanized, (Screw) Copper Alloy / galvanized, (Internal tooth washer) Steel / galvanized, (Bushing) Synthetic rubber |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Informasi Produk
Description
Fixing accessory that attaches to the plug and tightens the cable after connection.
Feature
A fixing clamp that attaches to the plug and relay receptacle and tightens the cable after wiring.Ulasan Produk
