- Inductive pencil-type measuring probes with stainless steel body Ø 8 h6 over the entire length
- Particularly suitable for comparison measurements due to their excellent repeatability (0.15 µm)
- Half-Bridge Output Type
- Reading speed up to 3900 values per second, depending on configuration
- Extremely robust ball bearing guide guarantees a minimum of 10 million cycles when the probe is not subjected to a lateral force
- Available in 2 versions :
- Spring pressure, measuring force 0.7 N
- Pneumatic thrust, the probe is retracted when it is not supplied with air (1 to 3 bar), pressure influencing the measuring force (0.4-0.7 N)
- Measuring range +/- 2 mm and +/- 5 mm
- Resolution up to 0.0001 mm (0.1 µm)
- Cable outlet protected by a spring which can be tilted by 90° with the optional accessory 901-5110
- PUR cable length 2 m.
- IP65 protection with Viton bellows
SYLVAC Inductive Probe
#Grup produk P106526154
Sebelum PPN:
Rp9.899.900 - Rp14.999.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Accuracy of Reading (%) | 0.5 |
|---|---|
| Body Diameter (mm) | 8h6 |
| IP Rating | IP65 |
| Repeatability (µm) | 0.15 |
| Resolution | Digital : user selectable to <0.1um |
| Temperature (%FS per°C) | 0.01 |
