Spesifikasi
Dimension (WxHxD) (mm) | 48.0x48.0x61.3 |
---|---|
Power Voltage (V) | 24-240 a.c. 50/60 Hz, 24-240 d.c |
Ambient Humidity | 35-85% RH (Without condensation) |
Ambient Temperature (°C) | -10 to 55 |
Dielectric Strength | 2000 V a.c. 50/60Hz For 1min |
Insulation Resistance (MΩ) | Min. 100 (500V d.c Mega standard) |
Power Consumption (W) | Max. approx. 2.5 (240V d.c.) |
Relay Life | Mechanical life : min. 10million times; Electrical life : More than 100 thousand times |
Return Time (s) | Max. 0.1 |
Shock Resistance (m/s) | 300(30 G) |
Storage Temperature (°C) | -20 to 65 |
Vibration Resistance | 10-55Hz (For 1 min) double amplitude 0.75mm |
Voltage Fluctuation Rate | ±10 % of power voltage |
Pilih jenis produk yang diinginkan
Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
---|---|---|---|---|
Loading... |
Informasi Produk
Feature
- Output operation modes (6 types)- Multi range (4 types)
- Time units (4 types)
- Reset, start and inhibit inputs
