WEIDMULLER Solid-state Relays 3-48VDC 0.1A Output Versions Push in Connection LM3RZF
#Grup produk P106130434
Spesifikasi
| Depth (mm) | 32.2 |
|---|---|
| ETIM 6.0 | EC002643 |
| ETIM 7.0 | EC002643 |
| GTIN (EAN) | 4032250000000 |
| Depth (inch) | 1.268 |
| Height (inch) | 1.579 |
| Brochures | FL DRIVES EN FL DRIVES DE |
| Catalogues | Catalogues in PDF-format |
| Height (mm) | 40.1 |
| Height of lowest version (mm) | 36.6 |
| Net Weight (g) | 54.1 |
| Order No. | 1770520000 |
| Packaging | Box |
| Product data | IEC: 630 V / 15 A / 0.2 - 2.5 mm² UL: 300 V / 10 A / AWG 24 - AWG 14 |
| Qty (pcs) | 10 |
| Type | LM3RZF 5.08/33/135 3.5SN DKGY BX PRT |
| Version | Printed circuit board terminals, 5.08 mm, Number of poles: 33, 135°, Solder pin length (l): 3.5 mm, Basalt grey, Tension-clamp connection, Clamping range, max. : 2.5 mm², Box |
| Width (inch) | 2.228 |
| Width (mm) | 56.58 |
