Mitutoyo DISK MICROMETER 75-100/0.01MM 169-207
#Grup produk P106113783
Spesifikasi
| Range (mm) | 75-100 |
|---|---|
| Graduation (mm) | 0.01 |
| Anvil dia. (mm) | 20 |
| Flatness (µm) | 1 |
| Parallelism (µm) | 6 |
| Maximum Permissible Error J MPE (µm) | ±6 |
| Measuring Force (N) | 3-8 |
| Mitutoyo Part Number | PDM-100 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Feature
- Measures “root tangent length” of spur gears and helical gears. - Determination of the root tangent length: refer to “Quick Guide to Precision Measuring Instruments” on page B-68.
- Non-rotating spindle type.
- Measurable range of gear pitch: 0.5 to 6 module (series 227: 0.4 to 3 module).
- Equipped with Ratchet Stop for constant measuring force.
- Supplied with a setting standard (except for 0 to 25 mm/0 to 1 in measuring range).
Use
Technical Data : • Battery for series 369 and 227 SR44 (1 pc.), 938882, for initial operational checks (standard accessory) • Battery life: Approx. 2.4 years under normal use (for 369-2XX, 3XX) Approx. 5 year under normal use (for 369-4XX) Approx. 5 years under normal use (for 227-2XX) - Length standard: Electromagnetic rotary sensor (for 369-2XX, 3XX) Electrostatic capacity absolute sensor (for 369-4XX, 2XX) - Standard accessories: Reference bar, 1 pc. (except for measuring range 0 to 10 mm/0 to 15 mm/ 0 to 25 mm/0 to 30 mm (0 to 1/0 to 1.2 in) models) Spanner (301336), 1 pc. (for 169-2XX, 369-2XX, 3XX) Screwdriver (210183), 1 pc. (for 227-2XX)Ulasan Produk
