Mitutoyo Digimatic Durometer
#Grup produk P106103564
Spesifikasi
| Display | Digital |
|---|---|
| Shore Scale | A |
| Applications | Natural Rubber, Soft Elastomers, etc. |
| Resolution | 0.1 |
| Range | 33147 |
| Digital Functions | Data Hold, Zero Setting, SPC Output, Power On-Off, SR44 Battery |
| Dimensions (mm) | 60x28.5x151 |
| Indenter Diameter (mm) | 1.25 |
| Indenter Protrusion (mm) | 2.5 |
| Indenter Tip Diameter (mm) | 0.79 |
| Indenter Tip Type | Blunt Taper |
| Model | HH-336 |
| Pressure Foot (mm) | 44x18 |
| Spring Force | WA=550+75HDmN |
| Standard | JIS K 6253, ASTM 2240, ISO 868, ISO 7619, JIS K 7215 |
| Tip Angle (°) | 35±0.25 |
| Type | Compact |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
The Mitutoyo Hardmatic digital and analog Durometer provides accurate, repeatable hardness test results on various soft materials from rubber and neoprene to leather and plastics. A data hold function (digital models) and peak retaining hand (on analog models) allows for error-free reading.
Feature
Units are available in both Shore A and Shore D scales and will test a wide variety of applicationsLCD screen on digital models provides easy-to-read results
Data output function transfers measurements to PC or a printer (via optional RS-232 interface)
Designed in accordance with the ASTM D 2240, ISO868, ISO 7619, DIN 53 505, JIS K 6253, and JIS K 7215 specifications
