The surface mount terminal type seal structure IP67 (IEC-60529) equivalent that achieves high reliability by the seal structure ensures high contact reliability even in dusty places and around water. * Excluding the terminal.
Surface mount terminal type suitable for high-density mounting.
A series with a grounding terminal that is convenient for electrostatic countermeasures is also available.
OMRON Sealed Surface Mount Tactile Switch B3S
#Grup produk P105952325
Spesifikasi
| Type | 6mm square B3S-1000 series |
|---|---|
| Contact Configuration | 1a (normally open contact) |
| Ambient Relative Humidity (RH) | 35~85 (at +5~+ 35 ° C) |
| Contact Resistance (miliΩ) | 100 or less (initial value) (DC5V 1mA energized) |
| Height (mm) | 4.3 |
| Insulation Resistance (MΩ) | 100 or more (at 250 VDC mega) |
| Operating Ambient Temperature (°C) | -25~+70 60% RH or less (no freezing or condensation) |
| Rating | DC3 ~ 24V + 1 ~ 50mA + Resistive load |
| Shock Resistance (m/s2) | Up to 1000 |
| Shock Resistance Malfunction (m/s²) | Up to 100 |
| Vibration Resistance (Malfunction) | 10~55Hz double amplitude 1.5mm |
| Withstand Voltage | AC500V 50/60Hz 1min |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
Surface Mount Terminal Types with High Reliability by Seal Structure Seal Structure IP67 (IEC-60529) equivalent to ensure high contact reliability even with dusty places and water circulation. Except for the terminal part.
Surface mount terminal type suitable for high density mounting.
Series with a ground terminal that is convenient for electrostatic measures.
