OMRON Round Waterproof Connector (M8/S8) with Cable Socket Plug Both Sides Connector XS3W
#Grup produk P105951885
Spesifikasi
| Rated Current (A) | 1 |
|---|---|
| Operating Temperature Range (°С) | -25 to +70 |
| Tensile Strength | Cable: 49N / 15s |
| Insulation Resistance (MΩ) | 1000 or more (at DC 500V) |
| Contact Material | Phosphor bronze |
| Contact Resistance (miliΩ) | (Connector) 40 or less (DC 20mV or less, 100mA or less) |
| Cover Material | Soft PBT (UL94V-0) |
| Material (Contact Block) | PBT resin (UL94V-0) / light gray or black |
| Material (Fixing Bracket) | Brass / nickel plated or SUS316L |
| Material (O-ring) | Rubber |
| Protection Class | IP67(IEC529) |
| Rated Voltage (V) | DC125 |
| Withstand Voltage (V/minute) | (Connector part) AC1000 (Leakage current 1mA or less) |
