OMRON I/O Relay Terminal G7TC
#Grup produk P105937113
Spesifikasi
| Ambient Humidity (% RH) | 35 to 85 |
|---|---|
| Case Color | Transparent |
| Contact Configuration | 1ax8 |
| Contact Resistance (miliΩ) | 50 or less (DC5V 1A) |
| Contact Type | Single |
| Insulation Resistance (MΩ) | 100 (500V mega) |
| LED Color | Green |
| Maximum Switching Frequency (times/hour) | 18000 |
| Noise resistance | Noise level 1.5kV, pulse width 100ns to 1μs |
| Operating Ambient Temperature (°C) | 0 to +55 (with no icing or condensation) |
| Operating Time (ms) | 15 or less |
| Power Supply Voltage (V) | DC12 |
| Rated Current (mA) | DC12V ... 46xON points DC24V ... 25xON points |
| Rated Voltage | DC12V±5% DC24V±5% |
| Shock Resistance Malfunction (m/s²) | 200 |
| Tensile Strength | Terminal: 49 / min |
| Vibration Resistance (Malfunction) | 10 to 55 to 10 Hz, single amplitude 0.5 mm (double amplitude 1.0 mm) |
| Withstand Voltage | Between coil and contact: AC2000V 50 / 60Hz 1min Between contacts of the same pole: AC1000V 50 / 60Hz 1min Between connectors: AC250V 50 / 60Hz 1min |
