High capacity basic switch with 20A current capacity and 75A inrush current.
The external shape is the same as the basic switch for Z type except for the push button position, but it has the ability to withstand 75A inrush current.
OMRON High Capacity Basic Switch A
#Grup produk P105937016
Spesifikasi
| Protection Class | IP00 |
|---|---|
| Rated Current (A) | 20(AC250V) |
| Insulation Resistance (MΩ) | 100 or more (with DC500V mega) |
| Rated Voltage (V) | AC250 |
| Allowable Operating Speed (mm-m/s) | 0.01 to 1 |
| Allowable Operation Frequency (times/minute) | (mechanical) 240 (electrical) 20 |
| Ambient Relative Humidity (RH) | 35 to 85 |
| Contact Specifications | Rivet |
| Electric Shock Protection Class | Class II |
| Electrical Durability (times) | 500,000 or more |
| Impact Resistance Durability (m/s²) | Up to 1000 |
| Inrush Current (A) | Normally closed: Max. 75 Normally open: Max. 75 |
| Mechanical Durability (times) | 1,000,000 or more |
| Operating Ambient Temperature (°C) | -25-80 (no icing) |
| PTI (Proof Tracking Index) | 175 |
| Shock Resistance (Malfunction) | Max.300m / s <sup>2</sup> (Malfunction within 1ms Pin push button type) |
| Vibration Resistance (Malfunction) | 10 to 55Hz, double amplitude 1.5mm (malfunction 1ms or less) |
| Withstand Voltage (V/minute) | Between terminals of the same polarity: 1000 AC 50/60Hz 1 Between live metal parts and ground, between each terminal and non-live metal parts: 2000 AC 50/60Hz 1 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
High-capacity basic switches of current capacity 20A and inrush current 75A. The external shape has the performance that withstands the 75A inrush current, while the pushbutin position is removed.
