Large cutoff capacity of 15A and high accuracy. (Repeatability is good)
Basic type of micro switch.
OMRON Basic Switch for General Purpose Z Standard Type Small Force Hinge Lever
#Grup produk P105932817
Spesifikasi
| Internal capacity | 1 piece |
|---|---|
| Actuator Type | Small force hinge lever type |
| Product Number | Z-15GW455-MD-1M |
| Rated Voltage (V) | AC125, 250, 500, DC8, 14, 30, 125, 250 |
| Contact Configuration | 1c |
| Classification | Standard |
| Conformity Standard | UL, CSA, TUV (EN61058-1), CCC (GB14048.5) |
| Contact Resistance (miliΩ) | 15 or less (initial value) |
| Dimensions (mm) | 38.2x49.2x17.45 |
| Impact Resistance (Durability) | Up to 1000m/s |
| Impact Resistance Malfunction (m/s) | Maximum 300 |
| Insulation Resistance (MΩ) | 100 or more (at DC500V mega) |
| Lead Wire Length (mm) | 1000 |
| Mass (g) | About 22-58 |
| Operating Ambient Humidity | 35-95% RH |
| Operating Ambient Temperature (°C) | -15-80 (however, do not freeze) |
| Protective Structure | Drip-proof Type: IP62 equivalent (excluding Terminals) |
| Terminal Type | SoldeRing Terminals |
| Vibration Resistance (Malfunction) | 10-55Hz Double amplitude 1.5mm (malFunction within 1ms) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
Suspended capacity is large and high, and high accuracy. (Repeated accuracy is good) Microswitch basic type.
