Large cutoff capacity of 15A and high accuracy. (Repeatability is good)
Basic type of micro switch.
OMRON Basic Switch for General Purpose Z Standard Type Reverse Operation Hinge/Roller/Short Lever
#Grup produk P105932774
Spesifikasi
| Rated Voltage (V) | AC125, 250, 500, DC8, 14, 30, 125, 250 |
|---|---|
| Allowable Operating Speed (mm-m/s) | 0.01 to 1 (value of push button) |
| Vibration Resistance (Malfunction) | 10 to 55Hz, double amplitude 1.5mm (malfunction 1ms or less) |
| Ambient Relative Humidity (RH) | 35 to 95 |
| Applicable Standard | UL, CSA, TUV(EN61058-1), CCC(GB14048.5) |
| Type Of Actuator | Reverse acting hinge, roller, short lever type |
| Classification | Standard |
| Contact Configuration | 1c |
| Contact Resistance (miliΩ) | 15 or less (initial value) |
| Dimensions (HxWxD) (mm) | 41x49.2x17.45 |
| Impact Resistance Durability (m/s²) | Up to 1000 |
| Insulation Resistance (MΩ) | 100 or more (with DC500V mega) |
| Internal capacity | 1 piece |
| Operating Ambient Temperature (°C) | -15-80 (however, do not freeze) |
| Protection Class | Drip-proof type: Equivalent to IP62 (excluding terminals) |
| Shock Resistance Malfunction (m/s²) | 300 (malfunction within 1ms) |
| Withstand Voltage | (Between same pole terminals) AC1500V 50 / 60Hz 1min, (between charging metal part and ground, between each terminal and non-charging metal part) AC2000V 50 / 60Hz 1min |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
Suspended capacity is large and high, and high accuracy. (Repeated accuracy is good) Microswitch basic type.
