Large cutoff capacity of 15A and high accuracy. (Repeatability is good)
Basic type of micro switch.
OMRON Basic Switch for General Purpose Z Standard Type Hinge, Cross, Roller, Short Lever
#Grup produk P105932473
Spesifikasi
| Internal capacity | 1 piece |
|---|---|
| Actuator Type | Hinge, cross, roller, short lever type |
| Product Number | Z-01HW49 |
| Rated Voltage (V) | AC125, DC8, 14, 30 |
| Contact Configuration | 1c |
| Classification | For micro loads |
| Conformity Standard | UL, CSA, TUV (EN61058-1), CCC (GB14048.5) |
| Contact Resistance (miliΩ) | 50 or less (initial value) |
| Impact Resistance (Durability) | Up to 1000m/s |
| Impact Resistance Malfunction (m/s) | Maximum 300 |
| Insulation Resistance (MΩ) | 100 or more (at DC500V mega) |
| Mass (g) | About 22-58 |
| Mechanical Durability | More than 20 million Times |
| Operating Ambient Humidity | 35-85% RH |
| Operating Ambient Temperature (°C) | -25-80 (however, do not freeze) |
| Protective Structure | General form (IP00) |
| Terminal Type | SoldeRing Terminals |
| Vibration Resistance (Malfunction) | 10-55Hz Double amplitude 1.5mm (malFunction within 1ms) |
| Withstand Voltage | (Between same pole Terminals) AC600V 50/60Hz 1min, (between charging Metal Part and Ground, between each Terminal and non-charging Metal Part) AC2000V 50/60Hz 1min |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
Suspended capacity is large and high, and high accuracy. (Repeated accuracy is good) Microswitch basic type.
