Mitsubishi Electric Inverter Freqrol-D700 Series, Single-Phase 200V
#Grup produk P105904498
Sebelum PPN:
Rp3.199.900 - Rp6.799.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Frequency Tolerance | ±5% |
|---|---|
| Frequency (Hz) | 50/60 |
| Type | Simple and compact inverter (FREQROL-D700 series) Single-phase 200V |
| Ambient Humidity (% RH) | 90 or less (no condensation) |
| AC voltage allowable fluctuation (V) | 170～264(50/60Hz) |
| DC braking | Operating frequency (0 to 120Hz), operating time (0 to 10s), operating voltage (0 to 30%) variable |
| Output Frequency (Hz) | 0.2～400 |
| Output overload current rating | 150% 60s, 200% 0.5s (reverse time characteristic) |
| Power Supply Voltage (V) | Single phase 200-240 (50Hz / 60Hz) |
| Protective structure (JEM1030) | Closed type (IP20) |
| Type of control | Soft-PWM control / High carrier frequency PWM control (V / F control, general-purpose magnetic flux vector control, optimum excitation control can be selected) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Feature
New standard for Mitsubishi inverterThe spring clamp terminal (control circuit) realizes high reliability and easy wiring. Equipped with a safety stop function and a hardware cut-off circuit for highly reliable emergency output cut-off.
Equipped with best-in-class performance in compact body
The compact body (3.7K or less) with the same mounting dimensions as our smallest inverter, the FR-S500 series, is equipped with general-purpose magnetic flux vector control, achieving a high torque of 150% (3.7K or less) at 1Hz.
Enhanced functions
Optimal for fan/pump application Excitation control/PID control, Machine tool application for deceleration/stop function during power failure, General purpose magnetic flux vector control for conveyor/food application/Brake resistor connection (0.4K to 15K), etc. It was equipped with.
