Mitsubishi Electric Cc-Link Ie Field Network Remote I/O Module
#Grup produk P105899099
Spesifikasi
| Isolation Voltage (V) | Between all DC external terminals and ground: AC500 for 1 minute |
|---|---|
| Ambient Operating Humidity | 5 to 95%RH, non-condensing |
| Mass (kg) | 0.3 |
| Impact Resistance | Conforms to JIS B 3502 and IEC 61131-2 (147m/s<sup>2</sup>, 3 times each in XYZ 3 directions) |
| Degree of Protection | IP2X |
| Power Supply | [Unit] Voltage: DC24V (ripple ratio within 5%) (allowable voltage range DC20.4 to 28.8V), current: 100mA or less (DC24V, all points ON) |
| Connection Method | [External wiring] Communication part: RJ-45 connector, unit power supply part: One-touch connector for power supply/FG (sold separately), input/output part: Sensor connector (e-CON) (sold separately) |
| Ambient Temperature (°C) | 0 to 55 |
| Atmosphere | No corrosive gas |
| Cable | [Communication] Ethernet cable that meets 1000BASE-T standard: Category 5e or higher, (double shielded/STP) straight cable |
| Common Specifications | [Input] 32 points/common (Sensor connector (e-CON) type 3-wire type) |
| Dimension (Height H x Width W x Depth D) (mm) | 50x194x68 |
| Input Format | DC input (plus common type) |
| Input resistance | 5.7k ohm |
| Installation Location | In the control panel |
| Insulation Method | [Input] Photocoupler insulation |
| Insulation Resistance | Between all DC external terminals and ground: 500 V DC, 10 M ohm or more with insulation resistance tester |
| Number of Input Points | 32 points, maximum simultaneous: 100% |
| Rated Input Current (mA) | 4.0 TYP.(DC24V) |
