This current sensor has a Hioki PL14 output connector, enabling it to be automatically recognized when connected to a compatible instrument for simple setup.
The sensor has the adequate frequency characteristics (amplitude) and temperature characteristics for not only current measurement but also high-accuracy power measurement.
Hioki AC Current Sensor
#Grup produk P105858630
Kondisi Barang:
Spesifikasi
| Rated Measurement Current (A) | 600 AC |
|---|---|
| Output Rate (mV/A) | 1 |
| Measurable Conductor Diameter (mm) | φ46 or less |
| Operating Temperature and Humidity (°C) | -10 to 50 (14°F to 122°F) 80% RH or less (no condensation) |
| Storage Temperature and Humidity (°C) | -20 to 60 (-4°F to 140°F) 80% RH or less (no condensation) |
| Dimensions (WxHxD) (mm) | Approx. 78x152x42 (3.07in.x5.98in.x1.65in.) |
| Accessories | Instruction Manual, Current Sensor Operating Precautions |
| Cable Length (m) | Approx. 2.5 (98.43in.) |
| Dielectric Strength (kV) | 8.54 AC (sensed current: 1 mA) for 1 minute (between jaw and grip, between jaw and output connector) |
| Dustproofness and Waterproofness | IP40 (EN60529) (with sensor connected and jaw closed) |
| Maximum Extendable Length (m) | By 10 (depends on the instrument to which the device is to be connected.) |
| Maximum Rated Voltage to Earth (V) | 1000 AC (Measurement category III), 600 AC (Measurement category IV), Anticipated transient overvoltage: 8000V |
| Operating Environment | Indoors, Pollution Degree 2, altitude up to 2000m (6562ft.) |
| Options | Model L0220-01 Extension Cable (2 m), Model L0220-02 Extension Cable (5 m), Model L0220-03 Extension Cable (10 m) |
| Standards | Safety: EN61010, EMC: EN61326 |
| Temperature coefficient | In the operating temperature range, add 0.02% rdg./°C (at temperatures other than 23°C±5°C). |
