Single-Range 500V/1000MΩ Analog Insulation Tester
Hioki insulation testers or megohmmeters feature all-in-one designs including built-in rugged cases and test lead storage compartments. The IR4018-20 is a single-range, 500V/1000MΩ analog insulation resistance tester with efficient functions and features to help shorten work time associated with field insulation testing.
Hioki Analog Megaohm HiTester
#Grup produk P105858375
Kondisi Barang:
Spesifikasi
| Effective Maximum Indication Value (MΩ) | 2000 |
|---|---|
| Overload Protection (V) | 1200 AC (10 sec.) |
| Dimensions (WxHxD) (mm) | 159 (6.26 in)x177 (6.97 in)x53 (2.09 in), (including battery, excluding test lead) |
| Accessories | Test Lead L9787 x1, LR6 (AA) alkaline batteries x4, Instruction manual x1, Shoulder strap x1 |
| Accuracy 1st Effective Measuring Range | ±5 % of indicated value; 2 to 1000 MΩ |
| Lower Limit Resistance (MΩ) | 1 (measurement resistance value to maintain testing voltage) |
| Other Functions | Bright LED luminous scale, Drop proof (on concrete, 1 m/1 time), Battery check, Live circuit check, Auto discharge |
| Power Supply | LR6 (AA) alkaline batteries x4, Continuous use: 15 hours (no load) |
| Rated Output Voltage (V) | 1000 DC |
| Voltage (V) | 0 to 600 (50/60 Hz), ±5 % of maximum scale value accuracy, 500 kΩ or more input resistance (AC) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
- Single range testing voltage of 500 V- Test insulation resistance up to 100 MΩ
- Built tough to withstand a 1-meter drop onto a concrete floor
- Bright LED luminous scale
- Check for live circuits and battery status
- Integrated hard case for quick and easy storage without disconnecting the leads
