Aruba Aruba 2930F 24G PoE + 4SFP Switch
#Grup produk P105646938
Spesifikasi
| Dimensions (cm) | 44.25x30.42x4.39 |
|---|---|
| Weight (kg) | 3.9 |
| Memory and Processor | Tri Core ARM1176 @ 625Mhz, 512MB SDRAM, 1 GB flash |
| Packet Buffer Size | 11.25MB (6.75MB dynamic egress + 4.5MB ingress) |
| Throughput (Mpps) | Up to 41.7 |
| Switching Capacity (Gbps) | 56 |
| Airflow Direction | Side-to-side |
| Frequency (Hz) | 50/60 |
| Idle Power (W) | 36.8 |
| Maximum Heat Dissipation (BTU/hour) | 258 |
| Maximum Power Rating (W) | 445 |
| Operating Temperature (°F) | 32 to 113 |
| PoE Power (W) | 370 PoE+ |
| Storage Temperature (°F) | -40 to 158 |
| Voltage | 100-127/200-240 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Warning
- Idle power is the actual power consumption of the device with no ports connected.- Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated.
- All hardware SKUs can be managed by Aruba Central. Central Managed (CM) SKUs are used for simplified ordering within U.S. and Canada only. Append "CM" to the indicated SKU : (e.g., JL261ACM to order the JL261A). Requires an active Central license and end-user information consistent with the Central license purchase. Applicable accessories with a valid "CM" suffix should also be placed on the same order.
Feature
Ports and slots:24 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
4 SFP
Additional ports and slots:
1 dual-personality (RJ-45 or USB micro-B) serial console port
