Robust Isolator

ex import japan technology
Size : Overall dimension (W x D x H) mm : 1760 x 800 x 1970
Working zone (W x D x H) mm : 1200 x 750 x 550
PASS BOX Size : Outer (W x D x H) mm : 550 x 550 x 800
Inner (W x D x H) mm : 380 x 380 x 620
Double door with interlock
Touch Screen &PLC system instr uctions :
1. ON/OFF the exhaust f an ;
2. frequency controlled fan speed ;
3. Monitor the DP inside & outside the work chamber, monitor the DP on both end of the fresh air HEPA; displa y
the DP between the two level exhaust HEPA f ilters and with alarm f unction.
4. Control opening/closing of air supply valve and air exhaust valve.
5. Control Inflating/deflating of the inflata ble seal strips.
Others:
1. Isolator work chamber is in SUS304; the rest material is steel plate with baking f inish.
2. the (ieanliness in work cham ber: ( class; both airflow
supplying and exhausting are from the top of the Isolator.
3. Airflow pattern: eddy.
4. Power Supply : AC250V , 21/J , 50Hz
5. work chamber is under negative pressure in normal operation.
6. Use round shape,polyformaldehyde glove port.
7. Use glove of USA brand NORTH, 10" , in HYPALO N material.
8. HEPA f ilter is of Comf il brand with filter ef f iciancy: > 99.95%
9. Use digital display DP sensor (from USA Dwyer> to monitor all the DP, and alarm if out of spec.
equipped DP gauges (f rom USA Dwyer> to display the DP between HEPA f ilters or inside & outside the work cham ber
10. This machine adopts inflata ble seal for air tightness.
11. Exhaust HEPA f ilter can be replaced in PUSH-PUSH way , which is similar to Bag-i n Bag-out.
