SIEMENS Burner Controls
#Grup produk P105196114
Spesifikasi
| Mains Voltage (V) | AC 220 - 15%...AC 240+10% |
|---|---|
| Input Current at Terminal 12 (A) | max. 5 within the permissible voltage range AC 187...264V or AC 195...253V |
| Current Rating Terminal 3 (A) | max. 3 (15A for max. 0.5s) |
| Current Rating Terminals 4, 5 and 7 (A) | max. 2 |
| Current Rating Terminals 9 and 10 (A) | max. 1 |
| Cable Length Terminals 8 and 10 (m) | 20 at 100pF/m |
| Current Rating Terminal 12 (A) | max. 5 |
| Degree of Protection | IP 40, when built in, with the exception of the connection area (terminal base) |
| Detector Cable Laid Separately (m) | 20 |
| Dimensions (WxHxD) (mm) | 91x62.5x62.5 |
| Main Frequency (Hz) | 50...60 ± 6% |
| Perm. Cable Lengths (m) | max. 3 at 100pF/m line capacitance |
| Power Consumption (V/A) | 3 |
| Primary Fuse (A) | max. 10 (slow) |
| Weight (g) | approx. 230 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
SIEMENS Burner Controls for the supervision of 1- or 2-stage gas or gas / oil burners of small to medium capacity (typically up to 350 kW), with or without fan, in intermittent operation.
