Sumitomo Electric Insert TNMG-GU
#Grup produk P103975836
Spesifikasi
| Hole Shape | Cylindrical hole |
|---|---|
| Corner Radius (mm) | 0.8 |
| Material | T1500Z |
| Shape | Equilateral triangle 60 degrees |
| Inscribed Circle Tolerance (mm) | +/- 0.05 to +/- 0.15 |
| Chip breaker | Both sides |
| Clearance Angle (degree) | 0 |
| Corner Height Tolerance (mm) | +/- 0.08 to +/- 0.2 |
| Cutting Blade Length (mm) | 16.5 |
| Inscribed Circle Diameter (phi mm) | 9.525 |
| Thickness (mm) | 4.76 |
| Thickness Tolerance (mm) | +/- 0.13 |
| With Or Without Hole | Yes |
