Spesifikasi
Display Format | analog |
---|---|
Overall Height (mm) | 1760 |
Vertical Movement of Main Scale | 25mm |
Maximum measurement length (mm) | 1500 |
Instrument Difference (mm) | 0.18 |
Mass (kg) | 26 |
Minimum Reading (mm) | 0.05 |
Mitutoyo Part Number | 514-170 |
Product Type | Body |
Vertical Movement of Slider Fine Movement (mm) | 20 |
Pilih jenis produk yang diinginkan
Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
---|---|---|---|---|
Loading... |
Informasi Produk
Warning
- Items with calibration documents cannot be canceled after ordering. - For products with proofreading and traceability charts, only orders on the web will be accepted. - Documents that include (JCSS Calibration Certificate), (General Calibration Certificate / Traceability System Diagram) and (Calibration Certificate / Traceability System Diagram) are included in the product number. - For products with calibration documents, " Mitutoyo Calibration Certificate with Traceability System Diagram '', which the manufacturer performs calibration, and " Calibration Company Implementation Calibration Certificate, '' which performs calibration at calibration points based on the calibration company based on the ISO 9001 quality management system With traceability system diagram ".Feature
- A rack mechanism is used for the moving parts necessary for zero-point alignment of the main scale. You can move the main scale and clamp quickly. - Large clamps can be used for both slider and fine feed clamps for easy clamping. - We adopt big main scale scale number which does not get tired even if we use for a long time. - Scriber (part number of standard accessory: 07GZA000) with a cemented carbide tip.Ulasan Produk
